Description

MODEL NUMBER

SCM-PD4CH

DESCRIPTION

The SHADOW-CASTER® SCM-PD4CH is a 4-position power distribution box that provides a convenient way to connect up to 4 SHADOW-CASTER® underwater lights. Digital over-current protection for each output insures safe operation of multiple lights and provides an easy way to manage the relatively high current switching needs of multiple light installations.

FEATURES

• Individual fuse for each light
• Color-coded quick connect terminals for intuitive installation
• Recommended when installing 3 or more underwater lights

SPECIFICATIONS

• Compatible with 12 or 24V systems
• Up to 10 amps per channel
• Up 4 AWG input power lugs
• IP67 wash down rated enclosure
