Description

Lumishore has expanded its industry-first LUX Lighting product range to include the world’s first CRGBW Flood Lights. Designed to offer a high-intensity light source onboard and perfect for deck, cockpit lighting, or for general security purposes.

This 4″ (10cm) light has an ultra-wide reaching (70° – 100°) oval beam angle for full coverage and custom diffusion optics for consistent and smooth beam colors. Generating a powerful 1,050 fixture lumens to illuminate your boat deck and beyond.

With its unique capability to combine warm and cold white (as well as red, green and blue) in a single lighting unit, LUX Flood Lights are unlike anything else on the market.

Lumishore’s low-profile articulating Flood Lights are ideal for exterior mounting on cabin tops, T-tops, arches, transoms and radar pedestals.

Designed to withstand the harshest marine environments, with a IP68 rating, and in marine-grade powder coated aluminium housing. The lighting units themselves are beautifully built, enhancing your boat’s fit-out, even when not in use.

Easily controllable by a switch, with the option to upgrade to full integration with your compatible MFD and/or Lumishore STV 2204-i Display with Lumi-Link.

SPECIFICATIONS

AVAILABLE COLORS:

White Color Temperature Tunable (2700K to 6500K) and Full Spectrum RGB

LUMENS:

2,360

FIXTURE LUMENS:

1,050

NUMBER & TYPE OF LED:

Warm White, Cold White, Red, Green and Blue (5 Channel)

LED POWER HICOB ARRAY:

Yes

TYPICAL LED LIFE:

50,000+ Hours

WARRANTY:

2 Years

USER CONTROL OPTIONS:

Lumi-Link Command Center or Customer Supplied Momentary Switch

ELECTRICAL INSTALLATION:

Simple 3 Wire Connection (see installation manual)

HOUSING TYPE:

Powder Coated Aluminium Body with Frosted Lens

DRIVER:

Multi-Channel Internal

SUPPLY VOLTAGE RANGE:

10.5—31 V DC

MAX CURRENT DRAW 12/24V:

1.7 A/0.9 A

BEAM ANGLE:

70° – 100° Oval Beam

WATER INGRESS PROTECTION RATING:

IP68
